Chassis Material: Extra Fully Hot Dip Galvanized chassis
Main Side Chassis rail : 4mm Special RHS+3mm reinforcement
Body Panel : Double Side Galvanized Steel Sheet
Roof : Special Molded FRP
Nuts& Bolts: Stainless Steel
Wheels& Tyres: Wheel Rim 15′ Aluminum Alloy Rims
Tyres: Five 195R-70R 15LT Tyres (includes a spare tyre)
Draw Bar Couplings: 50mm Ball Coupling
Drawbar Checker Plate: Aluminum Checker Plate
Drawbar Safety Chain : included
Jockey wheel: Heavy duty swing up jockey wheel
Floor & Rubber Matting
Floor: 18mm Whole sheet TUFF Board & 10mm whole sheet anti-slip Rubber Matting
Internal side board: whole sheet TUFF Board & aluminum board
Flooring of ramp door : 15mm whole sheet TUFF Board & whole sheet 15mm Rubber Matting
Suspensions& Axles
Axles: Two Special Axles 50x50mm
Leaf Springs : 8 Leaf Tandem Rocker Roller Suspension Spring
Brake System : Double axle electric brakes, front axle also with hand brake Brake away system
Windows& Doors
Front Window: 1220x 610mm
Side Windows : 5 slide windows
Vents :Two large size pop up vents
Side Door :1675x 670mm
Dust Door :1980x 1065mm
Ramp Door: 2030x 1210mm
Strut High-intensity Anti-rust Strut
Hinges For Dust Door Special 6mm diameter copper hinges
Electrical & Lighting
Lighting: Full LED lighting,
2 ✖interior LED Lights
2 ✖Taillights unit
1 ✖License Plate light Side marker lamps
6✖ mark lights
Wiring: 7-pin plug with certified AS/NZ standard
Mudguard
Mudguard Type: External Mudguards
Mudguard Checker Plate: Aluminum Checker Plate
Horse Protection Frame : Fully Padded
Horse Bay: 3-position adjustable horse stall, suitable for horses of different sizes.
2 bays with fold-bed
Horse Ring: 3 Internal & 4 Outside
Tack box: Swing out in back (1500mm Height)
Cabinet: a set of cabinet at the front of the float
Water tank: 70L water tank
A Hidden sink in the bench
External tap
Storage Box: Above the horse area
Painting: PPG Automative painting (customized color)
Overall Dimensions: 5925x2490x2600mm
Body Dimensions: 5075x1980x2230mm
Internal Dimensions:5050x1930x2155mm
Tare Mass : 1800KG
GVM : 3500KG
